EasyPact EZC-EZEUVRN024DC

undervoltage release UVRN – 24 V DC – for EZC250, EZCV250
Product Specifications
Part Number: EZEUVRN024DC
Base Unit of Measurement: PCE
Length: 0.87 dm
Gross Weight: 0.036 kg
ETIM-6.0: EC001022


Product Description

The under voltage release(UVRN) as the part of remote tripping is used for EasyPact EZC(V)250 circuit breakers. This UVRN is working at 24VDC voltage(Un). Tripping threshold is between 0.35 and 0.7times the related voltage. This release trips the circuit breaker when control voltage drops below a tripping threshold. Circuit breaker closing is possible only if the voltage exceeds 0.85 times the related voltage. This UVRN is internal mounting.
