Current transformer TI-METSECT5CC005

current transformer tropicalised DIN mount 50 5 for cables d. 21
Product Specifications
Part Number: METSECT5CC005
Base Unit of Measurement: PCE
Length: 8.2 cm
Gross Weight: 188 g
ETIM-6.0: EC002048
Product Description

This current transformer, tropicalised for cable, has a line rated current of 50 A and a secondary current rating of 5 A. This current transformer allow a maximum cable outer diameter of 21 mm. Burden and accuracy class as follows: class 1 maximum power: 1.25 VA, class 3 maximum power: 1.5 VA.
